Grandstream GWN7630 - Punto de acceso 4x4:4 MU-MIMO, PoE/PoE+
Número:
ART-127516
EAN:
6947273702870
MPN:
GWN7630
The GWN7630 is a high-performance 802.11ac Wave-2 Wi-Fi access point for small to medium sized businesses, multiple floor offices, commercial locations and branch offices. It offers dual-band 4×4:4 MU-MIMO technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range. To ensure easy installation and management, the GWN7630 uses a controller-less distributed network management design in which the controller is embedded within the product’s web user interface. The GWN7630 is also supported by GWN.Cloud, Grandstream’s free cloud Wi-Fi management platform. It is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi-capable IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 200+ concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, the GWN7630 is an ideal Wi-Fi access point for medium wireless network deployments with medium-to-high user density.
- 2.33 Gbps wireless throughput and 2 Gigabit wireline ports
- Dual-band 4×4:4 MU-MIMO technology
- Self power adaptation upon auto detection of PoE or PoE+
- Supports 200+ concurrent Wi-Fi client devices
- Up to 175-meter coverage range
- 2.33 Gbps wireless throughput and 2 Gigabit wireline ports
- Dual-band 4×4:4 MU-MIMO technology
- Self power adaptation upon auto detection of PoE or PoE+
- Supports 200+ concurrent Wi-Fi client devices
- Up to 175-meter coverage range
Solicitar información
¿Necesitas más información sobre este producto?
Ficha Técnica
Ficha Técnica
| 2,4 GHz | Si |
| 5 GHz | Si |
| Algoritmos de seguridad soportados | WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
| Altura | 45,9 mm |
| Altura del paquete | 86 mm |
| Ancho | 205,3 mm |
| Ancho del paquete | 258 mm |
| Botón de restaurar | Si |
| Calidad de servicio (QoS) soporte | Si |
| Cantidad de antenas | 4 |
| Certificación | FCC, CE, RCM, IC |
| Color del producto | Blanco |
| Consumo de energía (max) | 16,5 W |
| Distancia entre canales | 80 MHz |
| Energía sobre Ethernet (PoE) | Si |
| Estándares de red | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11e,IEEE 802.11g,IEEE 802.11n,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1x,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az |
| Ethernet LAN (RJ-45) cantidad de puertos | 2 |
| Ethernet LAN, velocidad de transferencia de datos | 10,100,1000 Mbit/s |
| Frecuencia de banda | 2.412 - 2.484; 5.18 - 5.825 GHz |
| Ganancia de la antena (max) | 5 dBi |
| Guía de configuración rápida | Si |
| Indicadores LED | Estado |
| Intervalo de humedad relativa para funcionamiento | 10 - 90% |
| Intervalo de temperatura de almacenaje | -10 - 60 °C |
| Intervalo de temperatura operativa | 0 - 40 °C |
| Kit de montaje | Si |
| MIMO | Si |
| Número de productos incluidos | 1 pieza(s) |
| Número de SSID admitidos | 15 |
| Número de usuarios | 200 usuario(s) |
| Peso | 590 g |
| Peso del paquete | 930 g |
| Potencia de transmisión | 27 dBmW |
| Profundidad | 205,3 mm |
| Profundidad del paquete | 247 mm |
| Protocolos de red compatibles | IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM |
| Rango máximo de transferencia de datos | 2330 Mbit/s |
| Rango máximo en exteriores | 175 m |
| Ranura para cable de seguridad | Si |
| Receptor de sensibilidad | 2.4G\n802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7\n5G\n802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:- 63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS |
| Soporte VLAN | Si |
| Tipo de antena | Interno |
| Tipo de ranura de bloqueo del cable | Kensington |
| Tipo MIMO | Multi User MIMO |
| Ubicación | Techo, Pared |
| Wi-Fi Multimedia (WMM)/(WME) | Si |
