Teltonika PR1KSG30, GNSS adhesive SMA antenna
Número: ART-152241 EAN: 4779051840397 MPN: PR1KSG30
Teltonika 003R-00250. Antenna gain level (max): 3.5 dBi, Frequency band: 1575.42-1602 GHz, Impedance: 50 ?. Antenna connector type: SMA, Connector gender: Male. Power consumption: 15 mA, Input voltage: 2.2 - 5 V
Tech Detail Table
Tech Detail Table
| Antenna connector type | SMA |
| Antenna gain level (max) | 2 dBi |
| Compliance certificates | RoHS |
| Connector gender | Male |
| Frequency band | 1.57542-1.602 GHz |
| Harmonized System (HS) code | 85177100 |
| Impedance | 50 ? |
| Input voltage | 2.2-5 V |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -40 - 85 °C |
| Polarization | Circular polarization |
| Power consumption | 15 mA |
| Power source type | DC |
| Product colour | Black |
| Quantity per pack | 1 pc(s) |
| Voltage Standing Wave Ratio (VSWR) | 1.5 |
